Use
The furnace mainly used for degreasing (decarburizing) and sintering of aluminum nitride,
silicon nitride and silicon carbide etc. under the condition of vacuum and high temperature ..
Main configuration:
1.Horizontal structure with built-in water cooling jacket. .
2.Graphite rod as heating element, electric resistance heating.
3 .Heating element along inner shell of furnace helps improving temperature uniformity.
4.Degreasing system consists of condenser and water cooling pipe joining to degreasing container,
good effect of degreasing.
5.Automatic control mode of PLC plus touching screen.
Main technical parameters:
| No. | Model | Max. Temperature | Working zone | Vacuum |
| （WXHXD）mm | ||||
| 1 | ZT-80-22 | 2000℃ | 200X200X300 | 5X10-2Pa |
| 2 | ZT-110-22 | 2000℃ | 250X250X350 | 5X10-2Pa |
| 3 | ZT-150-22 | 2000℃ | 300X300X500 | 5X10-2Pa |
| 4 | ZT-220-22 | 2000℃ | 400X400X600 | 5X10-2Pa |
| 5 | ZT-310-22 | 2000℃ | 500X500X750 | 5X10-2Pa |
Furnace can be customized on your request.
